AMD Ryzen 5 3500U vs AMD Ryzen 5 230
We compared two laptop CPUs: AMD Ryzen 5 3500U with 4 cores 2.1GHz and AMD Ryzen 5 230 with 6 cores 3.5GHz . You will find out which processor performs better in benchmark tests, key specifications, power consumption and more.
Main Differences
AMD Ryzen 5 230 's Advantages
Released 6 years late
Better graphics card performance
Higher specification of memory (7500 vs 2400)
Larger memory bandwidth (120GB/s vs 35.76GB/s)
Newer PCIe version (4.0 vs 3.0)
Higher base frequency (3.5GHz vs 2.1GHz)
Larger L3 cache size (16MB vs 4MB)
More modern manufacturing process (4nm vs 12nm)
Lower TDP (30W vs 35W)
Score
Benchmark
Cinebench R23 Single Core
AMD Ryzen 5 3500U
765
AMD Ryzen 5 230
+125%
1728
Cinebench R23 Multi Core
AMD Ryzen 5 3500U
2752
AMD Ryzen 5 230
+285%
10612
Geekbench 6 Single Core
AMD Ryzen 5 3500U
920
AMD Ryzen 5 230
+162%
2413
Geekbench 6 Multi Core
AMD Ryzen 5 3500U
2547
AMD Ryzen 5 230
+256%
9082
General Parameters
Jan 2019
Release Date
Jan 2025
AMD
Manufacturer
Amd
Laptop
Type
Laptop
x86-64
Instruction Set
x86-64
Picasso
Core Architecture
Zen 4 (Hawk Point)
-
-
-
FP5
Socket
FP8
Radeon Vega 8
Integrated Graphics
Radeon 760M
-
-
-
Package
4.9 billions
Transistor Count
25 billions
12 nm
Manufacturing Process
4 nm
-
-
-
12-35 W
Power Consumption
15-30 W
-
-
-
105 °C
Peak Operating Temperature
100 °C
-
-
-
-
Die Size
178 mm²
-
-
-
-
-
-
-
-
-
CPU Performance
4
Performance Cores
6
8
Performance Core Threads
12
2.1 GHz
Performance Core Base Frequency
3.5 GHz
3.7 GHz
Performance Core Turbo Frequency
4.9 GHz
-
-
-
-
-
-
-
-
-
-
-
-
4
Total Core Count
6
8
Total Thread Count
12
100 MHz
Bus Frequency
100 MHz
21x
Multiplier
35
-
-
-
96 K per core
L1 Cache
64 K per core
512 K per core
L2 Cache
1 MB per core
4 MB shared
L3 Cache
16 MB shared
No
Unlocked Multiplier
No
-
-
-
-
-
-
-
-
-
-
-
-
-
Memory Parameters
DDR4-2400
Memory Types
LPDDR5X-7500,DDR5-5600
32 GB
Max Memory Size
256 GB
2
Max Memory Channels
2
35.76 GB/s
Max Memory Bandwidth
120 GB/s
Yes
ECC Memory Support
No
Graphics Card Parameters
true
Integrated Graphics
true
300 MHz
GPU Base Frequency
800 MHz
1200 MHz
GPU Max Dynamic Frequency
2600 MHz
512
Shader Units
512
32
Texture Units
32
8
Raster Operation Units
16
8
Execution Units
8
65 W
Power Consumption
15
3840x2160 - 60 Hz
Max Resolution
-
1.13 TFLOPS
Graphics Performance
2.7 TFLOPS
AI Accelerator
-
NPU
AMD Ryzen™ AI
-
Theoretical performance
16 TOPS
