NVIDIA GeForce RTX 4070 Ti SUPER vs NVIDIA GeForce RTX 5070 Ti

We compared two Desktop platform GPUs: 16GB VRAM GeForce RTX 4070 Ti SUPER and 16GB VRAM GeForce RTX 5070 Ti to see which GPU has better performance in key specifications, benchmark tests, power consumption, etc.

Main Differences

NVIDIA GeForce RTX 4070 Ti SUPER 's Advantages
Boost Clock has increased by 6% (2610MHz vs 2452MHz)
Lower TDP (285W vs 300W)
NVIDIA GeForce RTX 5070 Ti 's Advantages
Released 1 years and 1 months late
Larger VRAM bandwidth (896.0GB/s vs 672.3GB/s)
512 additional rendering cores

Score

Benchmark

FP32 (float)
GeForce RTX 4070 Ti SUPER
44.1 TFLOPS
GeForce RTX 5070 Ti
43.94 TFLOPS
3DMark Time Spy
GeForce RTX 4070 Ti SUPER
24314
GeForce RTX 5070 Ti +13%
27607
3DMark Time Spy Extreme
GeForce RTX 4070 Ti SUPER
11874
GeForce RTX 5070 Ti +13%
13531
3DMark Speed Way
GeForce RTX 4070 Ti SUPER
6396
GeForce RTX 5070 Ti +20%
7699
VS

Graphics Card

Jan 2024
Release Date
Feb 2025
GeForce 40
Generation
GeForce 50
Desktop
Type
Desktop
PCIe 4.0 x16
Bus Interface
PCIe 5.0 x16

Clock Speeds

2340 MHz
Base Clock
2295 MHz
2610 MHz
Boost Clock
2452 MHz
1313 MHz
Memory Clock
1750 MHz

Memory

16GB
Memory Size
16GB
GDDR6X
Memory Type
GDDR7
256bit
Memory Bus
256bit
672.3GB/s
Bandwidth
896.0GB/s

Render Config

-
-
-
66
SM Count
70
8448
Shading Units
8960
264
TMUs
280
96
ROPs
96
264
Tensor Cores
280
66
RT Cores
70
128 KB (per SM)
L1 Cache
128 KB (per SM)
48 MB
L2 Cache
64 MB
-
-
-

Theoretical Performance

250.6 GPixel/s
Pixel Rate
235.4 GPixel/s
689.0 GTexel/s
Texture Rate
686.6 GTexel/s
44.10 TFLOPS
FP16 (half)
43.94 TFLOPS
44.10 TFLOPS
FP32 (float)
43.94 TFLOPS
689.0 GFLOPS
FP64 (double)
686.6 GFLOPS

Board Design

285W
TDP
300W
600 W
Suggested PSU
700 W
1x HDMI 2.1 3x DisplayPort 1.4a
Outputs
1x HDMI 2.1b 3x DisplayPort 2.1b
1x 16-pin
Power Connectors
1x 16-pin

Graphics Processor

AD103
GPU Name
GB203
AD103-275-A1
GPU Variant
GB203-300-A1
Ada Lovelace
Architecture
Blackwell 2.0
TSMC
Foundry
TSMC
5 nm
Process Size
5 nm
45.9 billion
Transistors
45.6 billion
379 mm²
Die Size
378 mm²

Graphics Features

12 Ultimate (12_2)
DirectX
12 Ultimate (12_2)
4.6
OpenGL
4.6
3.0
OpenCL
3.0
1.3
Vulkan
1.4
8.9
CUDA
10.1
6.7
Shader Model
6.8
